Wastewater Treatment: Equipment & Systems

CDF Industries designs, builds, and services the most complete line of Wastewater Treatment Systems available.  Our cutting edge technology and quality service has led to treatment solutions where many had failed before.

CDF Industries has a wastewater lab for wastewater analysis.  Analyzing your waste stream and taking into consideration your production and discharge limits, CDF Industries designs an entire treatment process with wastewater treatment equipment and chemicals.

CDF wastewater treatment machines feature small footprints, rugged construction and high capacity output. Automatic wastewater treatment systems use advanced Allen-Bradley, Micrologix PLC controls and heavy-duty agitators for years of dependable service.  From our economic manual wastewater treatment equipment to our large automatic treatment systems, CDF Industries has a wastewater treatment solution right for any application.

Our wastewater treatment products continue to be innovative in meeting clients’ needs in the industrial, municipal and oilfield wastewater markets.  CDF Industries offers complete wastewater treatment systems including tanks, auto-dosers, high speed mixers and dumpsters for solid waste.   We can custom design a waste treatment formula to accomodate strict discharge regulations or reuse of wastewater.  The sludge produced by our systems and treatment process is tested to be non-hazardous and able to go to a landfill.

CDF Industries works with your company to design a complete, environmentally friendly solution for your wastewater.


Manual Treatment Systems

Keep it simple.  These small economical systems treat volumes from 50 to 500 gallons per day.  The small footprint and light weight make the systems easy to move if needed.

CDF M125:

  • Max Throughput: 180 gph
  • 200 Gallon Holding Tank
  • 100 Gallon Treatment Tank
  • 100 Gallon Clean Water Tank
  • 1/4 cu yd Dumpster
  • Preplumbed for transfer pump
  • 1 HP Heavy Duty Agitator w/ Jet Basket
  • Optional Influent & Effluent Pumps
  • Optional Stainless Steel Construction

CDF M200

  • Max Throughput: 400 gph
  • 200 Gallon Treatment Tank
  • 200 Gallon Clean Water Tank
  • 1/2 cu yd Dumpster
  • 1 1/2 HP Heavy Duty Agitator w/ Jet Basket
  • Driven Bandfilter with roller for greater dewatering
  • Optional Influent & Effluent Pumps
  • Optional Stainless Steel Construction


Semi-Automatic Treatment Systems

This economical, space saving, semi-automated system requires less operator attention.  The semi-automatic system can be installed quickly.  Its features and capabilities go beyond any filter press system.

CDF SA200

  • Semi-Auto operation with Manual Overrides
  • Max Throughput: 400 gph
  • 200 Gallon Treatment Tank
  • 1/2 cu yd
  • Allen Bradley Controls
  • Single addition automatic chemical feed hopper
  • Access Platform
  • Stainless Steel Construction Standard

Automatic Treatment Systems

This economical, space saving, automated system requires little operator attention.  These systems can be installed rapidly.  The features and capabilities of these units go beyond traditional wastewater treatment systems.

CDF A200

  • Full automatic operation with Manual Overrides
  • Max Throughput: 600 gph
  • 200 Gallon Treatment Tank
  • Allen Bradley Micrologix PLC Controls
  • 1 1/2 HP Heavy Duty Agitator
  • Treatment tank auto washdown
  • Automatic Chemical Feed System
  • Double Rollers for Greater Dewatering
  • Optional Stainless Steel Construction
  • Optional pH Control System for Treatment Tank
  • Optional Effluent & Influent pumps
  • Auto Washdown for Filtrate tank

CDF A400

  • Same features as above, except:
  • Maximum Throughput: 1200 gph
  • 400 Gallon Treatment Tank
  • 3 HP Heavy Duty Agitator

CDF A800

  • Same features as above, except:
  • Maximum Throughput: 2400 gph
  • 800 Gallon Treatment Tank
  • Dual 3 HP Heavy Duty Agitators
